High Capacity Automatic Starchless Gummy Mogul Line Food Control Unit 30 moulds/min Specifications :
| Payment Terms | L/C T/T Western Union |
| Keyword | high capacity starchless gummy mogul line, advance gummy production line, Gummy Machine |
High Capacity Automatic Starchless Gummy Mogul Line Food Control Unit 30 moulds/min Detail Introduction :
High Capacity starchless gummy mogul line
Product Description
High Capacity starchless gummy mogul lines are a part of the Gummy Machine, SINOFUDE developed the high capacity starchless gummy mogul line all over the world which can reach to max 2000kg per hour with max 720pcs gummies per stroke. High Capacity starchless gummy mogul line is the ideal equipment to get high output for pectin base or gelatin base gummies production instead of the traditional starch mogul line. It can make Gummy candy with CBD or THC or Vitamin and Minerals. Etc functional products.
The high capacity starchless gummy mogul line is ideal equipment that can produce good quality gummies with the saving of both the manpower and the space occupied. Optional with Touch screen, SERVO and PLC for Automatic operation, mogul moulding system can make one color, two color or multi-color, center filled Gummy candy also available just change the manifold and nozzles. The cooling tunnel includes automatic Chain type/Air Knife/Brush de-molding system as option.
The high capacity starchless gummy mogul line was designed according to pharmaceutical machine standard, higher level sanitary structure design and fabrication, all stainless steel materials are SUS304 and SUS316L in the line and it can be equipped with UL certified or CE certified components for CE or UL certificated and FDA proved.
High Capacity Starchless Gummy Mogul Line FLOW CHART:
Syrup making→ mixing（with gelatin or pectin with CBD or THC or Vitamin and Minerals）→Stirring and holding→ transporting→ depositing → cooling → de-moulding →following disposal→Glazing or sugar coating→packing
Model | CLM2000-A |
Capacity ( kg/h) | Upto 2000 |
Speed (n/min) | Upto 30 moulds/min |
Candy weight (g): | Base on candy shape and size |
Electric power (kW) | 168 |
Chilling (option) | 40HP |
Compressed air C-Air pressure | 1.2m3/min 0.4-0.6 Mpa |
Conditions 1.Room temperature(℃) 2.Humidity (%) |
20~25C 45~55% |
Machine Length (m) | 22m |
Gross weight (Kgs) | 18000 |
